Application ＆ Characteristic
The unit is used in mixing various materials mixing, colouring, drying of different materials in the field of plastics, rubber, daily chemical industryand so on. It is an ideal choice for you to produce plastic plate, pipe, special-shaped material and degradation plastic.
The unit is developed by importing and absorbing overseas advanced technology. Mixing adopts negative pressure mixing principle.Theelectric equipments and meters all adopt imported famous brand. By adopting PLC control, it features high automatic level, good mixing result.
The vane is made of stainless steel pressure die cast, and haspassed the test of dynamic and static equilibrium. Especially thevane of the cooling machine adopts the spiral agitation. Thatmakes the whole room no dead angle, quickening the coolingspeed and discharging cleanly. The mixing result has come up tointernational advanced level.
Main Technical Parameter
|
Model／Specs |
SRL-W500/1600 Hot mixing/cold mixing |
SRL-W800/2000 Hot mixing/cold mixing |
SRL-W800/2500 Hot mixing/cold mixing |
SRL-W800x2/4000 Hot mixing/cold mixing |
SRL-W1000/2500 Hot mixing/cold mixing |
|
Total cubage(L) |
500/1600
|
800/2000
|
800/2500
|
1600/4000
|
1000/2500 |
|
Effective cubage(L) |
330/1000
|
560/1400
|
600/1500
|
1120/2700
|
700/1750 |
|
Mixing speed(rpm) |
860/70
|
660/55
|
660/60
|
700/65
|
700/50 |
|
Heating ＆ cooling manner |
electric heating self-friction／water cooling |
||||
|
Mixing time(min／batch) |
8-12 |
8-12 |
8-12 |
8-12 |
8-12 |
|
Motor power(kw) |
75/15
|
110/22
|
110/30
|
110x2/45
|
110/22 |
|
Discharge method |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
|
The heating and stirring are controlled by frequency conversion, and the electrical configuration varies according to the customer's mixed materials. |
|||||
|
|
